Drainage: Denver, NC
Get a Quote For Your Project
Street: Hawkes Bay Ct
Denver, NC United States
Problem: Water running on the side of house and foundational issues with water lingering.
If you have irrigation system, it is possible the irrigation may need to be moved for the slope dimensions to be correct. We are specialists in irrigation and can perform both at an expert level. Keeping your watering needs at a minimum loss and the water precipitation adequate for your property.
Solution: Installed French drainage system
Ran a French drainage, collection catch basin and gravel material to absorb dampness area on Property. Made all rain gutter connections and lead all corrugated tubes to a positive fall off.
Created a ¼ slope on your drainage. Drainage must have a slope every (foot) for it to work effectively and to make sure all the water exists tube.
I highly recommend a pop-up valve or if need be, an outlet that will easily let water out.
Contact Cell or text: Blue2green at 803 370 5211 for a FREE ESTIMATE.
If you live in the Greater Charlotte-Upper South Carolina Metro area, call or text us for a free estimate and see if we can help you elevate your landscape. 803- 370-5211
1. Planned the Drain Path
- Identified the water problem area (near foundation, soggy yard, etc.).
- Chose a route that leads downhill or slopes away from the house.
- Planned an exit point (e.g., curb, storm drain, or a dry well).
2. Marked and Dug the Trench
- Marked the trench path using spray paint or string.
- Trench dimensions:
- Depth: 18–24 inches (deeper if near foundations)
- Width: 6–12 inches
- Ensured a slope of at least 1 inch per 10 feet to ensure water flows.
3. Lined the Trench
- Laid landscape fabric inside the trench, allowing excess to wrap over the top after the gravel is added.
- This prevented sediment from clogging the system.
4. Added Base Gravel
- Poured 3–4 inches of gravel at the trench base.
- Compacted slightly and checked the slope again.
5. Laid the Perforated Pipe
- Used a perforated PVC or flexible corrugated drain pipe with the holes facing down.
- Connected multiple sections if needed and cap the high end.
6. Laid the Perforated Pipe
- Covered the pipe with at least 6 inches of gravel.
- Ensured gravel is even and maintains the trench slope.
7. Wrapped the Fabric
- Folded the landscape fabric over the top of the gravel.
- This prevented soil infiltration and extends drain life.
- Backfilled with soil and reseed grass, or
- Leave gravel was exposed with decorative stones.
At Blue2Green, we understand that effective drainage and irrigation are crucial for maintaining the health and beauty of your landscape. Our team of experts is dedicated to designing solutions that not only prevent water accumulation around your foundation but also ensure that every drop of water is utilized efficiently for your plants and lawn. With our innovative approach to system relocation and slope management, we tailor our services to your property’s unique topography, promoting optimal water distribution and reducing waste. Trust us to transform your outdoor space into a flourishing oasis where nature thrives and functionality meets aesthetic charm.
